No Position Loss After Power Failure with our AZ Series equipped with Absolute Sensor
What is our Absolute Sensor?
Highly Advanced Absolute Sensor
- This is a compact, battery-free mechanical absolute encoder.
Mechanical-Type Sensor
- The ABZO Sensor is equipped with multiple gears and detects position information by recognizing the angle of individual gears. As a result, it does not require a battery.
Multi-Rotation Absolute Encoder
- Absolute position detection is possible with ±900 revolutions (1800 revolutions) of the motor shaft from the reference home position.
No External Sensors Required
- As it is an absolute system, external sensors such as a home sensor or limit sensor are not required.
- *Please register or sign in to download
The Challenges
What are the challenges faced by Indian manufacturers?
- Power cuts causing position loss.
- Time wasted in re-homing machines.
- Production delays after every restart.
- Maintenance issues due to battery-based systems.
The Solution
Solve using our Oriental Motor AZ Series equipped with the Absolute Sensor
- No External Sensors Required.
- Improved High-Speed Return-to-Home + Return-to-Home Accuracy.
- Does not incur external sensor or wiring costs. It reduces the cost of the entire system..
- Increased Flexibility in Designing Equipment.
- Safe for Overseas Shipping
- Not Affected by External Sensor Malfunctions
Power Saving and Low Heat Generation
Significantly Reduced Heat Generation
-
Temperature Distribution by Thermography
This is an example of operation under the same conditions. -
Motor Surface Temperature During Operation Under the Same Conditions
Connector Type (IP66 rating) for Usage in Wet Conditions
With a degree of protection IP66 rating, it has a high dust-resistant performance and can be used in an environment where water droplets may splash on it.
A hollow shaft motor has been added to the standard type.
Air Pipe Can be Directly Connected to the Shaft. Reduces Design Time for Component Suction and Rotation Mechanisms
In air suction mechanisms for electronic components, directly connecting the air pipe to the hollow shaft eliminates the need for components such as belts and pulleys, reduces design time, lower costs, and save space. Furthermore, its light weight of only 70 g contributes to improved takt time when mounted on the end effectors.
Comparison by Air Suction Mechanism for Electronic Components etc.
When Using the Conventional Stepper Motor
When Using the AZ Series, Hollow Shaft
Network Compatible Drivers
Main Drivers
Compatible with all major industrial networks used around the world, contributing to centralized management of equipment information and reduced wiring. AC input driver is superior to DC input in terms of torque, and DC input driver is compact in comparison to AC input. Find for the purpose and application.
Also Available as Mini Drivers
Also Available as Multi-Axis Drivers
-
AC Input -
DC Input
|
|
|
| EtherCAT compatible | EtherNet/IP compatible | PROFINET compatible |
| AC input DC input |
AC input DC input |
AC input DC input |
|
|
|
| MECHATROLINK-III compatible | SSCNET III/H compatible | Built-in controller type |
| AC input | AC input | AC input DC input |
- *The built-in controller type can be controlled by CC-Link using network converters (gateway) sold separately.
Provides information on how to connect and set up when combining Oriental Motor products with other companies' products.
This is useful for designing programs and equipment startup.
Example of Applicable Manufacturer: OMRON Corporation/Mitsubishi Electric Corporation/Yaskawa Electric Corporation
